Ultegra 11sp
SKU
YQBN8

Bianchi Aria e-Road

Find your size

Enter any of these values
Your suggested size:
Out of stock
Find your nearest store
Recommended Retail Price
Add to Wish List
Loading...
€4,199.00 €4,600.00

Model 2021

POSITIONING
E-road light carbon bike, designed with aero tubes profiles.

COURSE/TERRAIN
Road, hilly fast courses and demanding climbs.

END USE DESTINATION
All-round riders with a true racing soul and a desire to take on long, demanding rides.

KEY FEATURES:
• Aero carbon frame and fork
• Full carbon seatpost with adjustable and reversible head
• Small and light motor unit
• Dedicated App for smartphone
• 7 sizes: 47, 50, 53, 55, 57, 59 and 61cm
• Racing geometry

Specifiche Tecniche

Tech specs

  • Motor Unit

    1. Motor

      Ebikemotion X35 Plus 250W motor unit, w/250Wh integrated battery and iWOC One remote control, BLE and ANT+ compatible

  • Frameset

    1. Frame

      Aria E-Road Disc carbon, mechanical/electronic shifting compatible, PressFit 86,5x41mm BB, head tube 1.1/4"-1.1/8", integrated seat clamp, full carbon dropout, flat mount, QR system, OLD 135mm, sizes 47-50-53-55-57-59-61cm

    2. Fork

      Bianchi Full Carbon Disc 1.1/4">1.1/8", thru axle 12x100mm

    3. Headset

      Fsa Orbit C-33, NO.44E, 1.1/8">1.1/4"

  • Drivetrain

    1. Shifters

      Shimano Ultegra ST-R8020 2x11sp, hydraulic disc brake, Shimano Ultegra ST-R8025 2x11sp, smaller lever size for sizes 47/53cm

    2. Rear Derailleur

      Shimano Ultegra RD-R8000 GS 11sp

    3. Front Derailleur

      Shimano Ultegra FD-R8000

    4. Crankset

      Shimano Ultegra FC-R8000 50x34T, Hollowtech II, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm

    5. Bottom Bracket

      Shimano SM-BB72-41B

    6. Chain

      Shimano Ultegra CN-HG701-11, 11sp

    7. Cassette

      Shimano 105 CS-R7000, 11-12-13-14-16-18-20-22-25-28-32T

  • Brakes

    1. Brakes

      Shimano BR-R8070

    2. BrakeLevers

      included w/shifters

    3. Rotor

      Shimano SM-RT86, diam. 160mm

  • Wheels

    1. Wheels

      Vision Trimax alloy disc, rear hub w/Ebikemotion X35 motor unit

    2. Tire

      Vittoria Rubino IV 700x28, 60TPI, G2.0 Graphene

  • Cockpit

    1. Stem

      Reparto Corse 3D Forged alloy 6061, rise - 8°, 1.1/8", Ext: 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59cm, 130mm-61cm

    2. Handlebar

      Reparto Corse Aero, alloy 6061 diam. 31,8mm, reach 74mm, drop 116mm, Size: 400mm-47/53cm, 420mm-55/59cm, 440mm-61cm

    3. Grips

      La Spirale Ribbon cork

  • Saddle

    1. Seatpost

      Aria Full Carbon Aero, clamp with alloy head adjustable and reversible +/- 35mm; length: 300mm-47/50cm, 350mm-53/61cm

    2. Saddle

      Selle Royal Seta S1, steel rails, 278x144mm

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
