Model 2020
The new Oltre XR3 benefits from the same revolutionary frame-design developments proven at the highest level of racing on the acclaimed Bianchi Oltre XR4. The Oltre XR3 delivers the perfect combination of control, and the competitive advantage of advanced aerodynamics.
POSITIONING
Racing disc frame and fork engineered with Countervail vibration cancelling technology,
a well-balanced fast road bike with aero profiles,
rigidity and handling you would expect from the ultimate Oltre frame platform but more affordable.
COURSE / TERRAIN
Road, flat and downhill segments, hilly and fast courses.
Oltre XR3 hydraulic disc brakes are impervious to adverse weather conditions.
Ride perfect lines at the optimum speed – for every single corner, rain or shine.
End USE DESTINATION
All-round riders with a true racing soul. Ideal for race warriors
KEY FEATURES
- Aero shape disc brake frame with integrated fork
- Thru axle 12mm x 100/142mm
- Flat mount calipers system
- Full carbon seatpost, easy to adjust
- Countervail technology to reduce muscle fatigue and support the best aero position
- Best performance-to-price ratio
DISC BRAKE SYSTEM
- Wider fork blade and rear dropout with flat mount system (Shimano standard)
- Thru axle 12mm x 100/142mm QR50 model with alloy lever
- Compatible with 140mm and 160mm rotor
AERO SEATPOST
- Aero seatpost with integrated look and adjustable head clamp offset (25mm or -10mm)
- Hidden seatpost clamp for perfect aerodynamic design and nice looking
FORK
- Full carbon 1.1/8” to 1.5” with Countervail® material
- Head crown tube 1.5” with integrated design for perfect head tube connection
- Flat mount system (Shimano standard) - Developed specifically for disc brakes
- Internal hydraulic cable guide housing
- Reactive geometry
- Super rigid- Light weight
Specifiche tecniche
-
Telaio
Kit Telaio
Oltre XR3 carbonio c/Countervail, compatibile trasmissioni meccaniche/elettroniche, foderi alti UTSS, forcellini carbonio, movimento centrale PressFit 86,5x41mm, pinza flat mount, asse passante 12x142mm, misure 47-50-53-55-57-59-61cmForcella
Bianchi Full Carbon c/Countervail, Disc, testa integrata 1.5", pinza flat mount, asse passante 12x100mmSerie sterzo
Fsa Orbit C-40-ACB
-
Trasmissione
Comandi
Shimano Ultegra ST-R8020 2x11v, freni a discoidraulici, Shimano Ultegra ST-R8025 2x11sp leve di dimensione ridotta per taglie 47/53cmCambio
Shimano Ultegra RD-R8000 SS 11vDeragliatore
Shimano Ultegra FD-R8000Guarnitura
Shimano Ultegra ST-R8020 2x11sp, hydraulic discbrake, Shimano Ultegra ST-R8025 2x11sp, smaller lever size for sizes 47/53cmMovimento Centrale
Shimano SM-BB72-41BCatena
Shimano Ultegra CN-HG701-11, 11vPacco pignoni
Shimano Ultegra CS-R8000, 11-12-13-14-15-17-19-21-23-25-28T
-
Freni
Freni
Shimano BR-R8070Leve freno
incluse c/comandiDischi
Shimano SM-RT800 Center Lock, diam. 160mm
-
Ruote
Ruote
Fulcrum Racing 418 disc brakePneumatici
Vittoria Rubino Pro G2.0 graphene 700x28
-
Manubrio
Attacco manubrio
Reparto Corse alloy 6061 forgiato 3D, angolo +/-6°, 1.1/8", lungh: 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59cm, 130mm-61cmPiega
Reparto Corse Aero Compact, alloy 6061 diam. 31,8mm, reach 74mm, drop 116mm, largh: 400mm-44/53cm, 420mm-55/59cm, 440mm-61cmNastro/manopole
La Spirale Ribbon cork
-
Sella
Reggisella
Oltre Full Carbon Aero; morsetto con testa in lega regolabile e reversibile +/- 35mm, lungh: 250mm-47cm, 300mm-50/53cm, 350mm-55/59cm, 380mm-61cm, arretramento: 25mm/-10mmSella
Fi'zi:k Antares R7
Bianchi si riserva il diritto di apportare cambiamenti, in base alla disponibilità dei componenti, senza preavviso.
