Model 2021

POSITIONING
Perfect combination between e-mobility and style. Frame designed to offer safer and more comfortable driving experience. The Bianchi motor unit is made in Italy.

COURSE / TERRAIN
Urban roads.

END USE DESTINATION
Designed to simplify your city commuting. A simple solution to urban travel.

KEY FEATURES:
• Aluminum step through frame with steel fork
• Motor: Bianchi 250W – 80Nm, 5 levels of assistance
• Battery: 418Wh
• Autonomy: up to 130km
• Shimano Hydraulic Disc Brakes
• Drivetrain: Shimano 1x9v 38T-11/36T
• Semi-integrated headset 1.1/8”
• Internal cable routing
• Rear dropout with kickstand predisposition
• Front and rear light motor unit battery powered EU and German approved
• Adjustable alloy stem 0°>90° and Alloy flat handlebar w/wing shape
• Sizes: 43, 47cm

Specifiche Tecniche

Tech specs

  • Motor Unit

    1. Motor

      Bianchi Central Motor Unit 36V - 250W - 80Nmw/418Wh 36v 11.6Ah Battery w/torque sensor,cadence sensor and speed sensor, w/digital display.Max speed 25kmh
  • Frameset

    1. Frame

      Long Island AL6061 stepthru frame, 700C, disc, welded rear carrier, w/battery cover insert, size 43,47cm
    2. Fork

      Bianchi Steel Disc, 700c
    3. Headset

      Fsa ZS4-Custom 1.1/8" w/15mm Alu cap
  • Drivetrain

    1. Shifters

      Shimano Altus SL-M2010 9sp
    2. Rear Derailleur

      Shimano Altus RD-M2000 SGS 9sp, Shadow Design
    3. Crankset

      Fsa Metropolis, solid forged alloy, ISIS, crank length: 170mm w/38T chainring
    4. Bottom Bracket

      Included w/motor unit
    5. Chain

      Shimano E-6070 9sp
    6. Cassette

      Shimano CS-HG200-9, 11-13-15-17-20-23-26-30-36T
  • Brakes

    1. Brakes

      Shimano BR-MT200
    2. BrakeLevers

      Shimano BL-MT200
    3. Rotor

      Shimano SM-RT10, 160mm, Center Lock
  • Wheels

    1. Wheels

      Aluminium, ETRTO 622x19C, Disc, 36 holes
    2. RearHub

      Formula CL-1422 Center lock
    3. FrontHub

      Formula CL-1420 Center lock
    4. Tire

      Vittoria Randonneur 700x38
  • Cockpit

    1. Stem

      Satori UP3 3D forged alloy, adjustable stem 0°>90° 1.1/8", 31.8mm, ext: 90mm
    2. Handlebar

      Satori Noirette Plus AL6061, diam. 31.8mm, 660mm width, rise 34mm, 41° backsweep
    3. Grips

      Spectra Bio Extra Ergo
  • Saddle

    1. Seatpost

      Alloy 6061 shaft, alloy head, 15mm offset, diam. 30.9mm, length 350mm
    2. Saddle

      Selle Royal Aurorae Elastomer
  • Accessories

    1. Pedals

      Included
    2. Mudguards

      700c, PVC, Width 50mm w/V stainless stays
    3. Kickstand

      Ursus R78 King rear, 28"
    4. RearCarrier

      welded on frame, alloy, w/Battery cover
    5. FrontLight

      Spanniga Axendo 40, 40 Lux, 1 white Led
    6. RearLight

      integrated in the battery

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.

Geometry
